RR-2.5R

Products specifications

Rated Cap.(tons)	2.5
Dimension (inches) D	1.75
Dimension (inches) E	1
Dimension (inches) F	1.5
Dimension (inches) G	4.25
Dimension (inches) J	9.56
Dimension (inches) L	26.88
Dimension (inches) O	1.09
Bail Dimension (inches) A	0.63
Bail Dimension (inches) B	3
Bail Dimension (inches) C	6
Bail Dimension (inches) T	0.63
Minimum Load(lbs) Basket	80
Minimum Load(lbs) Choker	40
Recommended Lifting Slings RopeDia.(inches)	5/8
Maximum Allowable Rigging Weight (lbs.) Basket	28
Maximum Allowable Rigging Weight (lbs.) Choker	14
cat	Model RR-R - Radio Controlled Release Unit
Product Features	· Allows rigging to be released from a safe <br /> distance with the push of a button. <br /> · Designed for rugged outdoor use. <br /> · Easy to use - simply rig, lift, set and release. <br /> · LOCK & CAPTURE feature engages with very little load weight <br /> (see Minimum Load in chart below). <br /> · Includes two 12 VDC 0.8 Amp Hr. sealed maintenance free <br /> lead acid batteries (rechargeable). <br /> · Includes one charger, and one vehicle adapter for standard <br /> 12 VDC vehicle outlets. <br /> · Battery life lasts through an 8 hour shift, depending on <br /> frequency of operation. <br /> · Minimum required cycle time is 1 - 2 minutes between releases. <br /> · Oversized bail for easy mounting on crane hook, 5 ton unit <br /> provided with fixed bail. <br /> · Designed and manufactured to ASME standards. <br /> 2-1/2 Ton Unit Shown <br /> Patent No. 7,380,849 <br />
Dimension (inches) K	31.15
Weight (lbs)	50
